PVC HOSE
High Quality Food Grade PVC Transparent Clear Hose
Food Grade PVC Clear Hose, also known as non-toxic food-grade hose, is a high-grade hose made from food-grade PVC material. It is mainly used in the food processing industry, including factories, farms, and home kitchens.
High Quality Food Grade PVC Transparent Clear Hose Overview
Features: 1. Odorless and tasteless PVC materials have the characteristics of high purity, non-toxic, and non-polluting. Therefore, food-grade PVC hoses made of this material are odorless, non-toxic, and food contact safe, making it very suitable for food processing and conveying.
2. High Transparency The clear PVC hose product is nearly transparent, which can ensure that the food processing and the conveying process can be monitored in real-time to ensure that there is no foreign material in the pipeline, and the hygiene level can be guaranteed.
3. Corrosion resistance and wear resistance The hose can withstand weak acid and weak alkaline solutions and performs well in high-pressure environments. It is also resistant to sludge, oil, and various chemicals, which extend its service life.
4. Smooth surface The internal wall of the hose is smooth, and the friction coefficient is small. The product can reduce energy consumption during transport and under high-speed flow situations.
5. Lightweight and flexible PVC hose is lightweight and flexible, making it easy to install, disassemble, and transport. It saves time and effort in the processing industry.
Applications: 1. In food processing industry The main application field of food-grade PVC clear hose is in the food processing industry, such as milk, beverages, beer, fruit juice, food additives, and other products transportation.
2. In pharmaceutical industry This type of hose can also be used in the pharmaceutical industry, mainly used for the transportation of pharmaceutical intermediate products, drug liquids, and other pharmaceutical raw materials.
3. In medical industry The hose is also applicable to hospitals and medical equipment because of its safety and cleanliness features.
4. In the automotive industry The hose is also widely used in car washes and car care services as it is safe for contact with vehicle Paintwork.
In conclusion, the Food Grade PVC Clear Hose is a high-quality and reliable product that finds application in various fields, mainly in the food processing industry, pharmaceutical and medical industries, as well as the automotive industry. It's features such as high transparency, smooth, flexible, and lightweight make it an ideal tool for many food operations. While considering the quality of food products, the use of this hose can be of greater benefit.
Key Features & Benefits
1. Flexible 2. Durable 3. Resistant to cracking 4. Wide range of applications 5. Smooth tube for resistance to collection or blockage
Product Details

Technical Specifications
The High Quality Food Grade PVC Transparent Clear Hose is available in the following specifications:
Product Numbler (inch) | Inner Diameter (mm) | Size (mm) | Outer Diameter (bar) | Working Pressure (psi) | Size (bar) | Burst Pressure (psi) | Size (g/m) | weight (m) | coil |
|---|---|---|---|---|---|---|---|---|---|
SY-CTFG-003 | 1/8 | 3 | 5 | 2 | 30 | 6 | 90 | 16 | 100 |
SY-CTFG-004 | 5/32 | 4 | 6 | 2 | 30 | 6 | 90 | 20 | 100 |
SY-CTFG-005 | 3/16 | 5 | 7 | 2 | 30 | 6 | 90 | 25 | 100 |
SY-CTFG-006 | 1/4 | 6 | 8 | 1.5 | 22.5 | 5 | 75 | 28.5 | 100 |
SY-CTFG-008 | 5/16 | 8 | 10 | 1.5 | 22.5 | 5 | 75 | 37 | 100 |
SY-CTFG-010 | 3/8 | 10 | 12 | 1.5 | 22.5 | 4 | 60 | 45 | 100 |
SY-CTFG-012 | 1/2 | 12 | 15 | 1.5 | 22.5 | 4 | 60 | 83 | 50 |
SY-CTFG-015 | 5/8 | 15 | 18 | 1 | 15 | 3 | 45 | 101 | 50 |
SY-CTFG-019 | 3/4 | 19 | 22 | 1 | 15 | 3 | 45 | 125 | 50 |
SY-CTFG-025 | 1 | 25 | 29 | 1 | 15 | 3 | 45 | 220 | 50 |
SY-CTFG-032 | 1-1/4 | 32 | 38 | 1 | 15 | 3 | 45 | 430 | 50 |
SY-CTFG-038 | 1-1/2 | 38 | 44 | 1 | 15 | 3 | 45 | 500 | 50 |
SY-CTFG-050 | 2 | 50 | 58 | 1 | 15 | 2.5 | 37.5 | 880 | 50 |
Applications
Used for conveying drinking water,beverage, wine, beer, jam and other liquid in food, pharmaceutical and cosmetics industries.

Packaging

Why Choose Our High Quality Food Grade PVC Transparent Clear Hose?
Premium quality materials ensure long-lasting performance
Available in multiple sizes to meet diverse requirements
Manufactured to meet international quality standards
Suitable for a wide range of industrial applications
