Rubber Hose
High Pressure PVC & Rubber Hybrid Air Hose
PVC Air Hose: The Durable and Versatile Solution If you’re looking for a high-quality air hose that can handle a range of jobs, look no further than PVC air hose.
High Pressure PVC & Rubber Hybrid Air Hose Overview
PVC air hose is also highly versatile, thanks to its compatibility with a wide range of fittings and connectors. Whether you need to connect to a standard air compressor, a specialized tool, or a custom setup, you can rely on PVC air hose to provide a secure, leak-free connection. And with a range of sizes available, you can find the perfect fit for your needs. One of the key benefits of PVC air hose is its excellent weather resistance. Whether you're using it in hot, dry conditions or cold, wet environments, this hose will maintain its strength and flexibility. UV-resistant and insulated against extreme temperatures, it can handle temperatures as low as -25°F and as high as 150°F. This makes it ideal for use in a variety of climates and settings, from arid desert regions to humid coastal areas. But perhaps the biggest advantage of PVC air hose is its ease of use. Lightweight and flexible, it is easy to maneuver and transport, making it a favorite among DIY enthusiasts and professional contractors alike. Its high-quality construction also ensures that it will hold up over time, even with frequent use. So if you're looking for a high-quality air hose that can handle anything you throw at it, consider PVC air hose. With its durable construction, versatile performance, and ease of use, it's the ideal choice for anyone looking to get the job done right.
Key Features & Benefits
1. lightweight, flexible and long lasting life. 2. kink-resistant, resistance to weathering, moisture 3. Non-marring, oil and abrasion resistant cover 4. high pressure provides plenty of air flow 5. working temperature: -5℃ to +65℃
Product Details
Technical Specifications
The High Pressure PVC & Rubber Hybrid Air Hose is available in the following specifications:
Product Number | Inner Diameter (mm) | Size (mm) | Outer Diameter (bar) | Working Pressure (psi) | Size (bar) | Burst Pressure (psi) | Size (g/m) | Weight (m) | Coil |
|---|---|---|---|---|---|---|---|---|---|
SY-PAH20-006 | 1/4 | 6 | 11.5 | 20 | 300 | 60 | 900 | 102 | 100 |
SY-PAH40-006 | 1/4 | 6 | 12 | 40 | 600 | 120 | 1800 | 115 | 100 |
SY-PAH20-008 | 5/16 | 8 | 14 | 20 | 300 | 60 | 900 | 140 | 100 |
SY-PAH40-008 | 5/16 | 8 | 15 | 40 | 600 | 120 | 1800 | 170 | 100 |
SY-PAH20-010 | 3/8 | 10 | 16 | 20 | 300 | 60 | 900 | 165 | 100 |
SY-PAH40-010 | 3/8 | 10 | 17 | 40 | 600 | 120 | 1800 | 200 | 100 |
SY-PAH20-013 | 1/2 | 13 | 19 | 20 | 300 | 60 | 900 | 203 | 100 |
SY-PAH40-013 | 1/2 | 13 | 20 | 40 | 600 | 120 | 1800 | 245 | 100 |
SY-PAH20-016 | 5/8 | 16 | 24 | 20 | 300 | 60 | 900 | 340 | 50 |
SY-PAH40-016 | 5/8 | 16 | 25 | 40 | 600 | 120 | 1800 | 390 | 50 |
SY-PAH20-019 | 3/4 | 19 | 28 | 20 | 300 | 60 | 900 | 450 | 50 |
SY-PAH30-019 | 3/4 | 19 | 29 | 30 | 450 | 90 | 1350 | 510 | 50 |
SY-PAH20-025 | 1 | 25 | 34 | 20 | 300 | 45 | 675 | 560 | 50 |
SY-PAH30-025 | 1 | 25 | 35 | 30 | 450 | 90 | 1350 | 640 | 50 |
Applications
used for transfer of air, water, light chemicals, equipped with pneumatic tools, pneumatic washing apparatus, air compressors, paint spray systems, engine components,pesticide spraying apparatus and civil engineering equipment in factories, workshops and other applications that require a generally purpose hose.
Packaging
Why Choose Our High Pressure PVC & Rubber Hybrid Air Hose?
Premium quality materials ensure long-lasting performance
Available in multiple sizes to meet diverse requirements
Manufactured to meet international quality standards
Suitable for a wide range of industrial applications
