Food Suction And Delivery Hose
The Food Suction and Delivery Hose is a specialized product designed for the safe and hygienic transfer of food and beverages in the food processing and packaging industries.
Food Suction and Delivery Hose
Optimize your sanitary fluid handling and heavy-duty processing lines with our premium Food Suction and Delivery Hose. Specifically engineered using FDA-compliant compounds, this high-grade hose features a white EPDM or NBR rubber construction that ensures maximum purity during food, beverage, and dairy transfer. The robust integrated steel wire helix provides superior structural strength for full vacuum suction service, while the ultra-smooth white inner tube prevents material accumulation and bacterial contamination.
Technical Specifications
| Product Code | Inner Diameter (ID) | Outer Diameter (OD) | Working Pressure (WP) | Burst Pressure (BP) | Weight | Standard Length | |||
|---|---|---|---|---|---|---|---|---|---|
| inch | mm | mm | bar | psi | bar | psi | kg/m | m | |
| SY-MFSD-019 | 3/4" | 19 | 30.4 | 10 | 150 | 30 | 450 | 0.67 | 60 |
| SY-MFSD-025 | 1" | 25 | 36.4 | 10 | 150 | 30 | 450 | 0.84 | 60 |
| SY-MFSD-032 | 1-1/4" | 32 | 44.8 | 10 | 150 | 30 | 450 | 1.2 | 60 |
| SY-MFSD-038 | 1-1/2" | 38 | 51.4 | 10 | 150 | 30 | 450 | 1.5 | 60 |
| SY-MFSD-051 | 2" | 51 | 64.4 | 10 | 150 | 30 | 450 | 1.93 | 60 |
| SY-MFSD-064 | 2-1/2" | 64 | 78.4 | 10 | 150 | 30 | 450 | 2.55 | 60 |
| SY-MFSD-076 | 3" | 76 | 90.8 | 10 | 150 | 30 | 450 | 3.08 | 60 |
| SY-MFSD-102 | 4" | 102 | 119.6 | 10 | 150 | 30 | 450 | 4.97 | 60 |
| SY-MFSD-152 | 6" | 152 | 171.6 | 10 | 150 | 30 | 450 | 8.17 | 30 |
*Note: Standard continuous warehouse roll lengths vary based on the specific diameter sizing. Alternate custom configurations of 30 meters or 60 meters per coil can be fully tailored to accommodate your exact bulk marketplace deployment and fleet distribution requirements.
Ordering Specifications & Bulk Customization Options
- Minimum Order Quantity (MOQ): 300 meters per size to support competitive B2B factory-direct wholesale pricing scales.
- Coil Length Options: Highly adaptable roll choices available in continuous lengths of 30 meters or 60 meters per roll.
- Premium Reinforcement: Dual-action reinforcement utilizing high-tensile textile plies integrated with a high-strength steel wire spiral helix to reliably support dual suction and delivery tasks without collapsing.
- FDA-Compliant Core: Formulated with a premium, smooth white EPDM or NBR rubber compound that completely eliminates chemical taste or smell transfer to beverages and dairy products.
Sanitary Food-Grade Dual Suction and Delivery
Developed to perform flawlessly through intense vacuum and positive-pressure cycles within modern commercial processing lines, this versatile food suction hose incorporates a weather-defying and ozone-resistant outer cover. The premium white inner tube resists temperature shifts during routine hot water washdowns or regular CIP (Clean-In-Place) sanitation cycles, guaranteeing an optimized fluid transit velocity with zero contamination risks.
Industrial Food Processing Applications
- Dairy & Milk Processing: High-volume sanitary transfer pathways for raw milk, heavy cream, whey, and processed dairy liquids.
- Beverage & Brewery Plants: Dual-action pumping networks for beers, wines, fruit juices, potable water, and spirits.
- Bulk Food Tankers: Heavy-duty, suction-rated loading and unloading lines for industrial transport trucks and railcars.
- Process Line Feeding: Reliable, flexible connections under constant vacuum forces feeding central processing equipment.
Why Choose Our Food Suction & Delivery Hose?
As an established high-capacity industrial hose manufacturer, we supply global B2B buyers with certified food-grade ducts built for extreme longevity and safety compliance. Our proprietary sanitary compound delivers exceptional flexible performance at a highly competitive B2B wholesale pricing structure. Reach out to our technical sales division today for volume price sheets and tailored private-label branding options.
Frequently Asked Questions (FAQs)
Q1: Can this food hose handle heavy vacuum suction applications?
A: Yes, absolutely. Unlike light delivery hoses, this hose features an embedded high-strength steel wire spiral helix reinforcement. This structure allows the hose to withstand heavy vacuum suction and negative pressure forces without collapsing, cracking, or restricting fluid flow.
Q2: Can I order specific custom coil lengths like continuous 30m or 60m rolls?
A: Yes, absolutely. Beyond the standard mill configurations listed in our technical data table, we support full custom roll cutting services. We can package each batch into 30-meter or 60-meter continuous coils depending on your localized distribution requirements.
Q3: Does the white EPDM or NBR inner tube affect the flavor of dairy or beverages?
A: Not at all. The internal tube is constructed from high-purity, FDA-compliant white rubber resins that are completely odorless and tasteless. This ensures that premium fluids like milk, wine, or juice maintain 100% of their organic sensory qualities during transfer.
Q4: Why do you enforce a 300-meter MOQ for wholesale orders?
A: Setting a 300-meter minimum order threshold per size lets us maximize our heavy-duty extrusion efficiency. This production advantage lowers processing costs and allows us to provide the most competitive factory-direct pricing for international distributors.
